Aerials/Aerials2005 (ImageServer)

View In: ArcGIS JavaScript ArcGIS Online Map Viewer ArcGIS Earth ArcMap

View Footprint In: ArcGIS Online Map Viewer

Service Description: This dataset is a single orthophoto from a collection of GeoTIFF format natural color orthophotos covering the Southwest Florida Water Management District. An orthophoto is remotely sensed image data in which displacement of features in the image caused by terrain relief and sensor orientation have been mathematically removed. Orthophotography combines the image characteristics of a photograph with the geometric qualities of a map. Each orthophoto provides imagery for a 5,000 foot by 5,000 foot cell area on the ground. The source imagery was obtained in January and February of 2005 and used to produce orthophotos with a one foot ground sample distance (GSD). Imagery was acquired at 0.85 foot GSD resolution. Flight height maintained during mission was 8,650 feet AGL. The imagery was captured at 12-bit radiometric resolution and converted to 8-bit radiometric resolution during post processing. The imagery was captured with 20% sidelap between all adjacent flight lines. The SWFWMD project area was divided into 10 flight blocks due to neccessary base station and flight line length requirements. The imagery was obtained and processed by all digital means beginning with data acquisition using an ADS40 digital sensor. The orthophotos are available in GeoTIFF form. The projected coordinate system is State Plane Florida West (Zone 902), NAD 83 HARN, GRS 80, Units Feet.

Name: Aerials/Aerials2005

Description: This dataset is a single orthophoto from a collection of GeoTIFF format natural color orthophotos covering the Southwest Florida Water Management District. An orthophoto is remotely sensed image data in which displacement of features in the image caused by terrain relief and sensor orientation have been mathematically removed. Orthophotography combines the image characteristics of a photograph with the geometric qualities of a map. Each orthophoto provides imagery for a 5,000 foot by 5,000 foot cell area on the ground. The source imagery was obtained in January and February of 2005 and used to produce orthophotos with a one foot ground sample distance (GSD). Imagery was acquired at 0.85 foot GSD resolution. Flight height maintained during mission was 8,650 feet AGL. The imagery was captured at 12-bit radiometric resolution and converted to 8-bit radiometric resolution during post processing. The imagery was captured with 20% sidelap between all adjacent flight lines. The SWFWMD project area was divided into 10 flight blocks due to neccessary base station and flight line length requirements. The imagery was obtained and processed by all digital means beginning with data acquisition using an ADS40 digital sensor. The orthophotos are available in GeoTIFF form. The projected coordinate system is State Plane Florida West (Zone 902), NAD 83 HARN, GRS 80, Units Feet.

Single Fused Map Cache: true

Tile Info:

Height: 256
Width: 256
DPI: 96
Levels of Detail: 20
- Level ID: 0 [ Start Tile, End Tile ]
- Level ID: 1 [ Start Tile, End Tile ]
- Level ID: 2 [ Start Tile, End Tile ]
- Level ID: 3 [ Start Tile, End Tile ]
- Level ID: 4 [ Start Tile, End Tile ]
- Level ID: 5 [ Start Tile, End Tile ]
- Level ID: 6 [ Start Tile, End Tile ]
- Level ID: 7 [ Start Tile, End Tile ]
- Level ID: 8 [ Start Tile, End Tile ]
- Level ID: 9 [ Start Tile, End Tile ]
- Level ID: 10 [ Start Tile, End Tile ]
- Level ID: 11 [ Start Tile, End Tile ]
- Level ID: 12 [ Start Tile, End Tile ]
- Level ID: 13 [ Start Tile, End Tile ]
- Level ID: 14 [ Start Tile, End Tile ]
- Level ID: 15 [ Start Tile, End Tile ]
- Level ID: 16 [ Start Tile, End Tile ]
- Level ID: 17 [ Start Tile, End Tile ]
- Level ID: 18 [ Start Tile, End Tile ]
- Level ID: 19 [ Start Tile, End Tile ]
Format: MIXED
Compression Quality: 75.0
LERC Error: NaN
Origin: X: -2.0037508342787E7
Y: 2.0037508342787E7
Spatial Reference: 102100 (3857)

Extent:

Initial Extent:

Full Extent:

Time Info:

[2001/01/01 00:00:00 UTC, 4860/01/01 00:00:00 UTC]

Pixel Size X: 0.3048006095923483

Pixel Size Y: 0.3048006095923485

Band Count: 3

Pixel Type: U8

RasterFunction Infos: {"rasterFunctionInfos": [{ "name": "None", "description": "", "help": "" }]}

Mensuration Capabilities: None

Has Histograms: false

Has Colormap: false

Has Multi Dimensions : false

Rendering Rule:

Min Scale: 5.91657527591555E8

Max Scale: 1128.497176

Copyright Text:

Service Data Type: esriImageServiceDataTypeRGB

Min Values: N/A

Max Values: N/A

Mean Values: N/A

Standard Deviation Values: N/A

Object ID Field: OBJECTID

Fields:

OBJECTID ( type: esriFieldTypeOID, alias: OBJECTID )
Shape ( type: esriFieldTypeGeometry, alias: Shape )
Name ( type: esriFieldTypeString, alias: Name, length: 50 )
MinPS ( type: esriFieldTypeDouble, alias: MinPS )
MaxPS ( type: esriFieldTypeDouble, alias: MaxPS )
LowPS ( type: esriFieldTypeDouble, alias: LowPS )
HighPS ( type: esriFieldTypeDouble, alias: HighPS )
Category ( type: esriFieldTypeInteger, alias: Category , Coded Values: [0: Unknown] , [1: Primary] , [2: Overview] , ...5 more... )
Tag ( type: esriFieldTypeString, alias: Tag, length: 20 )
GroupName ( type: esriFieldTypeString, alias: GroupName, length: 50 )
ProductName ( type: esriFieldTypeString, alias: ProductName, length: 50 )
CenterX ( type: esriFieldTypeDouble, alias: CenterX )
CenterY ( type: esriFieldTypeDouble, alias: CenterY )
ZOrder ( type: esriFieldTypeInteger, alias: ZOrder )
Shape_Length ( type: esriFieldTypeDouble, alias: Shape_Length )
Shape_Area ( type: esriFieldTypeDouble, alias: Shape_Area )
DateTime ( type: esriFieldTypeDate, alias: DateTime, length: 8 )

Default Mosaic Method: Northwest

Allowed Mosaic Methods: NorthWest,Center,LockRaster,ByAttribute,Nadir,Viewpoint,Seamline,None

SortField:

SortValue: null

Mosaic Operator: First

Default Compression Quality: 75

Default Resampling Method: Bilinear

Max Record Count: 1000

Max Image Height: 4100

Max Image Width: 15000

Max Download Image Count: 20

Max Mosaic Image Count: 20

Allow Raster Function: true

Allow Copy: null

Allow Analysis: null

Allow Compute TiePoints: false

Supports Statistics: true

Supports Advanced Queries: true

Use StandardizedQueries: true

Raster Type Infos:

Has Raster Attribute Table: false

Edit Fields Info: null

Ownership Based AccessControl For Rasters: null

Child Resources: Info Key Properties Legend Raster Function Infos

Supported Operations: Export Image Query Identify Compute Histograms Compute Statistics Histograms Get Samples Compute Class Statistics Query Boundary Compute Pixel Location Compute Angles Validate Project
